Item No.:AV-2000A


AV- 2000A series optical time domain reflectometer is a new generation of portable and intelligent measuring instrument designed by AVEIS COMMUNICATION (SHENZEN) CO., LTD. for testing optical fiber communication system. Adopt 5.8 inch color touch screen, button/ touch dual operation; Internal integration of eight major functional modules, multi-functional integration to help customers effectively solve the field test and maintenance .


1. Convenient one-button testing
2. High speed signal processing, less test time and fast analysis
3. Color TFT LCD
4. USB port connect to PC
5. Input optical signal auto detection and self-protection
6. Built-in VFL


It is mainly used to measure the length, loss and connection quality of all kinds of optical fibers and cables, and can be widely used in engineering construction, line maintenance and testing, emergency repair, and the development and production of optical fibers and cables.


Wavelength1310±20nm / 1550±20nm
Dynamic Range28dB / 26dB
Event Dead Zone< 1.5m
Attenuation Dead Zone< 8.0m
Pulse Width10ns, 25ns, 50ns, 100ns, 250ns, 500ns, 1000ns,2500ns,5000ns, 10000ns
Distance uncertainty±(1.0m ± 0.005% * testing distance ± resolution)
Linearity±0.05dB/ dB
Loss Resolution0.001dB
Distance Resolution1m
ConnectorFC (optional: SC, ST, LC)
Data Storage> 10000 traces (standard 1GB SD card)
Display3.5 inch TFT color LCD
BatteryBuilt-in rechargeable battery
Working Time>10 hours
Operating Temp.-10 — +50 ℃, < 90%RH
Storage Temp.-20 — +60 ℃, < 90%RH
Net Weight0.9 Kg

Accessories Package
