Item No.:AV-FSM02

Description

AV-FSM02 high-precision multi-functional optical fiber fusion splicer optical fiber fusion splicer uses the idea of Internet of Things to acquire welding machine data through sensor technology and GPS information technology, and uploads it to the fusion splicer management platform using wireless communication technology. Get this data and show, control, notify, and more. The administrator and the user realize the remote monitoring of the status and position of the fusion splicer through the platform, and the integrated management of the real-time command release of the fusion splicer. A good solution to most of the pain points currently in the management of fusion splicers.

Features

  1. Remotely query the version information, fault information, and device power of the device through the background management platform.
  2. The GPS location information can be queried through the background management platform: the electronic map visually displays the latest location information and dynamics of the device.
  3. The operation information can be queried through the background management platform: the number of times of welding of the device can be checked and the welding image can be obtained.
  4. The historical track playback can be queried through the background management platform: the motion track of the device can be viewed.
  5. The effective period and the number of welding times of the fusion splicer can be set remotely; the machine can also be locked remotely.
  6. Can remotely upgrade the fusion splicer.
  7. Through the platform, the administrator can obtain the usage status of all the devices, know how many active terminal devices and idle devices, and effectively allocate and allocate the devices to improve the device utilization.
  8. Through the platform, comprehensive, accurate and dynamic information on the total amount, composition, distribution and changes of equipment of each unit (department) can be obtained, which can improve the utilization rate of equipment, save investment in assets, and improve the standardization and scientific management of assets level.
  9. The working area of ​​the user of the device can be effectively managed through the electronic fence.
  10. The manager can set different permissions for subordinate users according to different identities, realize multi-type user classification, multi-level user classification, and realize hierarchical management and lease management.

Specifications

Applicable Optical Fiber TypesSM(single mode),MM(Multimode),DS,NZDS
Number of motors4 motors
Applicable  Optical Fiber DiameterCladding Diameter: 80-150μm,Coating diameter:100~1000μm
Fusion splice ModelPrestore:40 groups, User define: 80 groups
Average Fusion Splice Loss0.01dB(SM), 0.01dB(MM), 0.03dB(DS), 0.03dB(NZDS)
Return LossBetter than 60dB
Fusion splice  Duration Time7Sec(Typical Mode), 5Sec(Fast Mode)
Loss  Estimation of Fusion SpliceExist
Tension Test≥1.96N(Optional big rally fusion splicer 8N)
Display4.3 inches colorized LCD support Chinese, English, Spanish, Russian, French, Portuguese, etc.
Optical Fiber Magnification TimesX/Y:180 times, X or Y:350 times
Power Supply11.1V Lithium battery, 13.5V/5A power adapter
BatteryTypically work 200 cycles ( Splicing / Heating),

Full charge 3Hours, Recharge Cycle: 500 times, 6800mA Li-battery

Storage10,000 Records
Data InterfaceUSB2.0
Operating EnvironmentElevation:0~5000m, Relative humidity:0~95%,Temperature:-20°C~55°C,Maximum wind speed:15m/s
Storage EnvironmentRelative humidity:0~95%, Temperature:-40°C~80°C (Except Battery), Temperature:-10°C~40°C (Battery)
Weight1.66kg(without battery), 1.87kg(with battery)
Corrosion ResistanceEquipment components, Parts and materials meet composite anti-corrosion requirements, Anti-fluid pollution
Size158L×138W×138H(mm)
Working aloftNeed to configure the platform separately
AlignmentHigh precision core
Heating timeV-type 14 seconds heat shrink
Environmental monitoringAutomatic detection prompts user self-test and discharge correction when there are differences in temperature and humidity altitude
Multiple selection fixtureSplit and multi-function fixtures for both skin, bare, round and butterfly fibers
Safety protectionElectrical system protection program: lithium battery fireproof explosion-proof high temperature, circuit board to prevent over-current and over-voltage
Quality RecordsCan detect the angle and perpendicularity of the recording fiber and the angle between the fibers
Forced fusionForced fusion according to user requirements





Display5 inches colorized LCD support Chinese, English, Spanish, Russian, French, Portuguese, etc.
Optical Fiber Magnification TimesX/Y:250 times, X or Y:500 times
Power Supply11.1V Lithium battery, 13.5V/5A power adapter
BatteryTypically work 200 cycles ( Splicing / Heating),
Full charge 3Hours, Recharge Cycle: 500 times, 6800mA Li-battery
Storage10,000 Records
Data InterfaceUSB2.0
Operating EnvironmentElevation:0~5000m, Relative humidity:0~95%,Temperature:-20°C~55°C,Maximum wind speed:15m/s
Storage EnvironmentRelative humidity:0~95%, Temperature:-40°C~80°C (Except Battery), Temperature:-10°C~40°C (Battery)
Weight1.66kg(without battery), 1.87kg(with battery)
Corrosion ResistanceEquipment components, Parts and materials meet composite anti-corrosion requirements, Anti-fluid pollution
Size158L×138W×138H(mm)
Working aloftNeed to configure the platform separately
AlignmentHigh precision core
Heating timeV-type 14 seconds heat shrink
Environmental monitoringAutomatic detection prompts user self-test and discharge correction when there are differences in temperature and humidity altitude
Multiple selection fixtureSplit and multi-function fixtures for both skin, bare, round and butterfly fibers
Safety protectionElectrical system protection program: lithium battery fireproof explosion-proof high temperature, circuit board to prevent over-current and over-voltage
Quality RecordsCan detect the angle and perpendicularity of the recording fiber and the angle between the fibers
Forced fusionForced fusion according to user requirements

Accessories Package
